10GBase-LR SFP+ LC Transceiver – TL-SM5110-LR

10GBase-LR SFP+ LC Transceiver – TL-SM5110-LR

Overview: The TL-SM5110-LR is a high-performance 10GBASE-LR SFP+ transceiver module designed to extend the transfer distances of 10Gbps Ethernet connectivity. This single-mode SFP+ module operates at a 1310nm wavelength and supports full-duplex 10G Ethernet connections, making it an ideal solution for long-distance data transmission over fiber optic networks.

Key Features:

• High Performance: Supports 10Gbps data rate, ensuring fast and reliable network performance.
• Extended Distance: Capable of transmitting data up to 10 kilometers with 9/125µm single-mode fiber cables.
• Hot-Pluggable: Allows for easy installation and removal without interrupting network operations.
• Digital Diagnostic Monitoring (DDM): Provides real-time monitoring of parameters such as temperature, voltage, and optical power.
• Compatibility: Adheres to the SFP+ Multi-Source Agreement (MSA) standards, ensuring compatibility with a wide range of networking devices including switches, routers, and media converters.

Technical Specifications:

• Wavelength: 1310nm
• Fiber Type: Single-mode (9/125µm)
• Maximum Distance: 10km
• Data Rate: 10Gbps
• Port Type: LC Duplex
• Operating Temperature: 0–70°C (32–158°F)
• Storage Temperature: -40–80°C (-40–176°F)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing

Applications: The TL-SM5110-LR is perfect for use in data centers, enterprise networks, and other high-speed networking environments where reliable and efficient data transmission is critical. Its compatibility with various networking devices and adherence to industry standards make it a versatile and dependable choice for network administrators.

Conclusion: Enhance your network’s performance and reliability with the TL-SM5110-LR 10GBASE-LR SFP+ transceiver module. Its robust features and compatibility ensure seamless integration into your existing network infrastructure, providing high-speed connectivity and extended transmission distances.
