TP-LINK 24-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE+ Switch – TL-SL1226P

TP-LINK 24-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE+ Switch – TL-SL1226P

The TL-SL1226P 24-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE+ Switch is a robust and versatile networking solution designed to meet the needs of small to medium-sized businesses. This switch combines high-speed connectivity with advanced Power over Ethernet (PoE) capabilities, making it ideal for various applications, including surveillance and office environments.

Key Features:

• 24 PoE+ Ports: Equipped with 24 PoE+ 10/100Mbps RJ45 ports, each supporting up to 30W, allowing you to transfer data and power over a single cable.
• High PoE Power Budget: Supports a total PoE power budget of 250W, ensuring sufficient power for multiple devices such as IP cameras, access points, and IP phones.
• Additional Ports: Includes 2 gigabit RJ45 ports and 2 combo gigabit SFP slots for flexible connectivity options.
• Extended PoE Transmission: Up to 250 meters data and power PoE transmission range under Extend Mode, ideal for large area surveillance.
• Priority Mode: Ensures high priority for ports 1–8 to guarantee the quality of sensitive applications like video monitoring.
• Isolation Mode: One-click client traffic separation for higher security and performance.
• Plug and Play: Simple setup with no configuration required. Just connect your devices and start using the network immediately.

Technical Specifications:

• Interface: 24× 10/100Mbps PoE+ RJ45 ports, 2× gigabit RJ45 ports, 2× combo gigabit SFP slots
• PoE Ports: 24× PoE+ ports, up to 30W per port
• Total PoE Power Budget: 250W
• Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af/at
• Switching Capacity: 8.8Gbps
• MAC Address Table: 8K
• Packet Forwarding Rate: 6.55Mpps
• Power Supply: 100-240VAC, 50/60Hz
• Dimensions: 17.3 × 7.1 × 1.7 inches (440 × 180 × 44 mm)
• Max Power Consumption: 270W (with PoE)
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing

The TL-SL1226P is an excellent choice for businesses seeking a reliable, high-speed, and energy-efficient networking solution with PoE capabilities. Its advanced features and easy setup make it a top pick for enhancing network performance.
