Dahua XVR – DH-XVR5116H-4KL-I3(V2.0)

Dahua XVR – DH-XVR5116H-4KL-I3(V2.0)

Product Overview: The Dahua XVR – DH-XVR5116H-4KL-I3(V2.0) is a high-performance digital video recorder designed to support a wide range of surveillance applications. This 16-channel Penta-brid 4K Value/5MP Mini 1U 1HDD WizSense Digital Video Recorder is equipped with advanced AI features to enhance security and operational efficiency.

Key Features:

• SMD Plus (Smart Motion Detection Plus): Utilizes deep learning algorithms to improve alarm accuracy by analyzing human and vehicle shapes, significantly reducing false alarms.
• AI Coding: Reduces bit rate and storage requirements by up to 50% compared to H.265, without losing decoding compatibility.
• H.265+/H.265 Dual-Stream Video Compression: Efficiently compresses video to save bandwidth and storage.
• Versatile Compatibility: Supports HDCVI, AHD, TVI, CVBS, and IP video inputs, making it compatible with various camera types.
• High Definition Camera Input: Supports up to 4K HDCVI cameras and 8MP IP cameras.
• Long Distance Transmission: Supports long-distance transmission over coaxial cable, up to 700m for 4K/4MP, 800m for 1080P, and 1200m for 720P.
• Smart H.265+ Codec: Reduces bit rate and storage requirements by up to 90% compared to H.264.
• Face Recognition: Supports up to 2 channels of face recognition for analog channels, with a face database capacity of up to 20,000 images.
• Perimeter Protection: Supports up to 8 channels of perimeter protection for analog channels, with advanced AI capabilities for tripwire and intrusion detection.
• Privacy Protection: Supports masking and restoring human faces detected in real-time to ensure privacy.

Technical Specifications:

• Main Processor: Industrial-grade processor
• Operating System: Embedded Linux
• Video Input: 16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
• IP Camera Input: Up to 32 channels, each channel up to 8MP
• Video Output: 1 HDMI, 1 VGA
• Multi-screen Display: 1/4/8/9/16/25/36
• Network Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
• Mobile Phone Access: iOS, Android
• Interoperability: ONVIF 16.12, CGI Conformant
• Recording Playback: 1/4/9/16/25/36 channels
• Backup Method: USB device and network
• Power Supply: DC12V/2A
• Power Consumption: <10W (without HDD)
• Dimensions: 260mm × 236mm × 48mm (10.2″ × 9.3″ × 1.9″)
• Weight: 1.1kg (2.4lb) (without HDD)

Applications: Ideal for a wide range of applications, including residential, commercial, and industrial environments, the Dahua XVR – DH-XVR5116H-4KL-I3(V2.0) ensures reliable and high-quality video recording, enhancing security and peace of mind.
