Dahua IP Camera – DH-IPC-HDW1431SP-0280B-S4

Dahua IP Camera – DH-IPC-HDW1431SP-0280B-S4

Product Overview: The Dahua IP Camera – DH-IPC-HDW1431SP-0280B-S4 is a high-performance network camera designed to deliver exceptional video quality and reliable surveillance capabilities. This 4MP IR Fixed-focal Eyeball Network Camera is equipped with advanced features to ensure clear and detailed monitoring in various lighting conditions.

Key Features:

• 4MP CMOS Sensor: Provides high-quality 4MP resolution video at 25/30 fps, ensuring clear and detailed images.
• H.265 Codec: Offers high compression rate and ultra-low bit rate, saving bandwidth and storage.
• Built-in IR LED: Ensures clear images up to 30 meters in complete darkness.
• Wide Dynamic Range (WDR): Balances light and dark areas to provide clear images in high contrast lighting conditions.
• 3D Noise Reduction (3D NR): Reduces noise in low-light conditions for clearer images.
• IP67 Rating: Provides protection against dust and water, making it suitable for outdoor installations.
• Smart IR Technology: Adjusts the intensity of the camera’s infrared LEDs to prevent overexposure of objects close to the camera.

Technical Specifications:

• Image Sensor: 1/3″ CMOS
• Effective Pixels: 2688 (H) × 1520 (V), 4MP
• Lens: 2.8 mm, F2.0
• Field of View: Horizontal: 104°, Vertical: 57°, Diagonal: 125°
• Video Output: H.265, H.264, MJPEG
• Frame Rate: 4MP (20 fps), 3MP (25/30 fps)
• Operating Conditions: -30°C to +60°C (-22°F to +140°F), less than 95% RH
• Power Supply: DC 12V/PoE (802.3af)
• Power Consumption: <5W
• Dimensions: 110 mm × 93.2 mm (4.33″ × 3.67″)
• Weight: 0.42 kg (0.93 lb)

Certifications:

• CE: EN55032/EN55024/EN50130-4
• FCC: Part 15 subpart B, ANSI C63.4-2014
• UL: UL60950-1+CAN/CSA C22.2 No.60950-1

Applications: Ideal for a wide range of applications, including residential, commercial, and industrial environments, the Dahua IP Camera – DH-IPC-HDW1431SP-0280B-S4 ensures reliable and high-quality video recording, enhancing security and peace of mind.
