ProLink Copper Patch Cord PL-PC-U6-3OR

PROLINK U/UTP CAT.6 250 MHz Patch Cord (PL-PC-U6-3OR)

The PROLINK PL-PC-U6-3OR is a high-quality unshielded CAT.6 patch cord designed for connecting network equipment to patch panels and telecommunications outlets. Here are the key features:

1. Performance: Meets the requirements of Category 6, Class E (250 MHz) according to ISO/IEC 11801 standards.
2. Compatibility: Can also be used as Cat5e (backward compatible).
3. Quality Assurance: Each individual patch cord is rigorously tested and marked with a quality stamp.
4. Strain Relief: Provides robust strain relief for durability.
5. Labeling: Custom labeling possible on the strain relief or color-coding.
6. Length Options: Available in 3m.
7. Impedance: 100 ohms.
8. LSZH (Low Smoke Zero Halogen): Ensures safety in case of fire.
9. Color: Vibrant red for easy identification. (orange)

Technical Specifications:

• Plug Housing: Polycarbonate
• Contacts: Phosphor bronze (CuSn6) with 0.7 μm selective gold plating
• Voltage Rating: 300 VAC (maximum)
• Conductor Stranding: Solid
• Wire Size: #24 AWG
• Outside Diameter: 0.218 in (5.54 mm)

Whether you’re setting up a home network or a large-scale enterprise solution, the PROLINK PL-PC-U6-3OR ensures reliable connectivity and optimal performance. Choose quality, choose PROLINK!

Technical File
