TP-LINK 5-Port 10/100/1000Mbps Switch – LS1005G

TP-LINK 5-Port 10/100/1000Mbps Switch – LS1005G

The LS1005G 5-Port 10/100/1000Mbps Desktop Switch is a reliable and efficient solution for expanding your wired network. This switch is designed to provide high-speed connectivity and is ideal for home offices, small businesses, and other environments requiring robust network performance.

Key Features:

• Gigabit Ethernet Ports: Equipped with 5 auto-negotiation 10/100/1000Mbps RJ45 ports, supporting Auto-MDI/MDIX, ensuring fast and reliable data transfer.
• Energy-Efficient Technology: Incorporates Green Ethernet technology to reduce power consumption, making it an eco-friendly choice.
• Plug and Play: Simple setup with no configuration required. Just connect your devices and start using the network immediately.
• Fanless Design: Ensures quiet operation, making it suitable for noise-sensitive environments.
• Versatile Mounting Options: Features a compact plastic casing that can be placed on a desktop or mounted on a wall.

Technical Specifications:

• Interface: 5× 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
• Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Switching Capacity: 10Gbps
• MAC Address Table: 2K
• Packet Forwarding Rate: 7.4Mpps
• Jumbo Frame: 16KB
• Power Supply: External Power Adapter (Output: 5VDC/0.6A)
• Dimensions: 3.5 × 2.8 × 0.9 inches (90 × 72 × 23 mm)
• Max Power Consumption: 3.7W
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing

The LS1005G is an excellent choice for users seeking a cost-effective, high-speed, and reliable networking solution. Its advanced features and easy setup make it a top pick for enhancing network performance.
